PD 3-Wire Type-C Laptop Charging Connector — 3-Pin CC Capacitor Adapter
Keep your laptop charging system running smoothly with this PD 3-Wire Type-C Charging Head Connector. Designed for DIY repair and electronics prototyping, this 3-pin male Type-C connector features a built-in capacitor and dedicated CC pin (CTOC5 configuration), making it ideal for restoring or building USB-C Power Delivery charging circuits in notebooks and laptops.
Available in convenient 2-set or 10-set packs, these connectors are perfect for electronics hobbyists, repair technicians, and engineers who need reliable, solderable Type-C charging heads on hand.
Key Features
- PD-Ready Design: 3-wire configuration with CC pin (CTOC5) for USB-C Power Delivery compatibility
- 3 Solder Joints: Easy to solder onto PCBs and DIY charging boards
- Built-In Capacitor: Integrated capacitor for stable, consistent power negotiation
- 24V Rated: Supports low-voltage operation (below 50V AC or 75V DC)
- Durable Construction: Plastic and metal materials for lasting performance
- Value Pack: Choose from 2-set or 10-set quantities to suit your project needs
Specifications
| Connector Type | 3-Pin Male Type-C (CTOC5) |
| Configuration | 3-Wire with CC Pin |
| Voltage | 24V (Below 50V AC / 75V DC) |
| Solder Joints | 3 |
| Materials | Plastic, Metal |
| Pack Size | 2 Sets or 10 Sets |
| Country of Origin | Made in Mainland China |
