3-Way Electronic Crossover Board 6-Channel Stereo DIY Audio

HpLive 3-Way Electronic Crossover Board – 6-Channel Stereo Output

Take your DIY audio builds to the next level with this professional-grade 3-Way Electronic Frequency Crossover Board from HpLive. Featuring a precision Linkwitz-Riley filter network and six independent stereo output channels, this board delivers clean, distortion-free signal splitting for audiophile-quality sound reproduction in multi-amplifier speaker systems.

Key Features

• Advanced Linkwitz-Riley Crossover Design: Ensures smooth frequency separation with no peaks or valleys for accurate, natural audio reproduction across all bands.
• 6-Channel Stereo Output: Splits stereo left/right input into six independent channels — left/right treble, midrange, and bass — ideal for driving a full 6-channel amplifier setup.
• Replaceable & Adjustable Crossover Points: Fine-tune frequency crossover ranges to perfectly match your speaker drivers and audio system for optimized sound performance.
• Audiophile-Grade NE5532 Op-Amp: Powered by a precision dual NE5532 op-amp chip for ultra-low noise, high-fidelity signal processing and clean channel separation.
• DIY-Friendly Integration: Supports independent adjustments for each of the six output channels, ensuring seamless compatibility with custom multi-amplifier speaker builds.
• Gold-Plated Lotus Connectors: Four dual gold-plated lotus (RCA) sockets minimize signal loss and ensure reliable, high-quality connections.

Specifications

Package Contents

• 1 × 3-Way Electronic Crossover Frequency Board

Build the Perfect Audio System

Whether you're assembling a high-fidelity home audio setup or building a custom car sound system, this crossover board gives you precise frequency control. Pair it with your preferred amplifiers and speaker drivers for a truly tailored listening experience. If you're working on other DIY electrical projects, you might also find our Non-Contact Capacitive Water Level Sensor or 50Pcs Nickel Sheets for 18650 Battery Spot Welding Tool useful additions to your electronics workbench.

Learn more: EPA guidance on lithium-ion battery handling

Frequently Asked Questions

Q: What type of crossover filter does this 3-way frequency board use?

A: This crossover board uses a Linkwitz-Riley filter design with a -24 dB/Oct slope attenuation, which ensures smooth, accurate frequency separation between the bass, midrange, and treble bands with no unwanted peaks or phase issues.

Q: What are the default crossover frequency points on this board?

A: The default crossover points are 310 Hz and 3.1 kHz. This divides the audio spectrum into: Bass (20–310 Hz), Midrange (310 Hz–3.1 kHz), and Treble (3.1–20 kHz). The crossover points are replaceable/adjustable to suit your specific speaker system.

Q: What power supply does this crossover board require?

A: The board requires a dual (bipolar) AC transformer power supply in the range of ±14V to ±19V. It is not powered via USB or a standard DC adapter — a proper bipolar transformer supply is needed for correct operation.

Q: Is this board suitable for beginners in DIY audio?

A: This board is best suited for intermediate to advanced DIY audio enthusiasts who are familiar with multi-amplifier speaker setups and basic electronics wiring. Its independent channel adjustments and gold-plated RCA connectors make integration straightforward for those experienced with audio builds.
